So my windshield frame was rusted out all along the bottom. I knew it was pretty rusty but didn’t know the full extent until I folded it down and started chipping away at it with a screwdriver to probe for good metal. It was to the point of little support for the glass and would likely have collapsed in a rollover accident. I thought about taking the glass out, grinding away the paint and welding in some new metal. Too much work for a hack job. So I ordered a new frame from 4x4.com and some rattle cans of paint from automotivetouchup.com, 2 basecoat and 2 clearcoat. Also ordered new inner and outer rubber from Quadratec, and picked up some urethane and urethane primer locally.
The “primer” or whatever the frame came with (a semi-gloss black they called primer) was incompatible with my green paint so I painted over it with a couple coats of red filler-primer, a wet sanding, and then regular gray primer to smooth it out a bit. Then the metallic green and the clearcoat went on.
![Image]()
![Image]()
![Image]()
![Image]()
Took the old windshield assembly in the house and put the cab cover on it.
![Image]()
The old frame:
![Image]()
I used one of those cheap, breakaway utility knives to work away at cutting the old urethane adhesive-sealant because my regular Stanley knife wouldn’t reach deep enough with the blade fully extended.
It took several passes and some sweat. Tough stuff.
![Image]()
A single edged razor blade to cut it off the glass.
![Image]()
Using some pieces of duct tape to hold the new seal on the glass helped while it got worked around it, otherwise it popped off the sections I had already done. New urethane (I used 3M Windo Weld and its recommended primer) adhesive-sealant to set the glass and let it cure for a couple of days and nights. I also put some clear silicone sealant on the pinch weld lips to help keep moisture out, and blew 3M Rustfighter 1 inside the frame with compressed air where I couldn’t get paint very well.
![Image]()
Some of the old flat-head torx screws needed to be drilled out to remove the frame from the vehicle, so I replaced them with stainless steel allen-head screws.
![Image]()
Finally done!
